Description
Kinmore Motor
The delivery cycle is 15 days
| Warranty | 3months-1year | Place of Origin | Guangdong, China |
| Brand Name | Kinmore Motor | Model Number | RC-280SA-20125 |
| Use | Car, Electric Bicycle, FAN, Home Appliance, Door Lock Actuator,Hair Clipper,Massager,RC Model | Type | Micro Motor |
| Torque | Stall >230 g.cm | Construction | Permanent Magnet, Permanent Magnet |
| Commutation | Brush | Protect Feature | Drip-proof |
| Speed(RPM) | 11600 ± 10% rpm no load | Continuous Current(A) | on load <0.88 A |
| Efficiency | IE 1 | Frame | 24*30.6mm |
| Rated voltage | DC 9V | Rated Power | 4.5 W |
| Motor Mounting Type | Panel Mount | Speed Rpm | 11600 ± 10% rpm no load |
| Motor housing Size | L30.6mm*Dia24mm | Noise | <50dB |
| Nominal voltage | 9.0 V DC | Operating Temperture | -10~ +60 |
| Way of commutation | brushes | Rotation | CW/CCW |
| End Play | 0.05~0.35 mm | Bearing kind | Oil-impregnated bearing |
| Motor type | small wind turbine motor |
