Description
roundss
The delivery cycle is 14 days
| Series | High - end Incremental Photoelectric Encoder | Features | High - precision, replaceable, wide temp |
| Mounting Type | Shaft - mounted | Description | Servo encoder for industrial automation |
| Model Number | NVA48T9 | Type | Servo Motor Encoder |
| Place of Origin | Jilin, China | Brand Name | Roundss |
| Use | IAE, IWL, ME, RF | Output | Line Drive Output |
| Voltage - Supply | 5V±0.25 | Communication interface | RS422 BISS |
| Outer Diameter | 48mm | Shaft Diameter | 8mm; 9mm |
| Resolution-Single-turn | 17bit | Universal Rotating Speed | 6000rpm |
| Max Rotating Speed | 15000rpm | Breaking Strength of Shaft and Bearing | ≥650N |
| Max Response Frequency | 300kHz | Operating Temperature | -40°~+85℃ |
| Protection Class | IP50 |
| brand | roundss |
