Description
TTN
The delivery cycle is 15 days
| Application | home, Pump, motor, Home Appliance | Phase | Single Phase |
| Network | wifi | Place of Origin | Zhejiang, China |
| Brand Name | TTN | Model Number | 2.0KW,3.2KW,4.2KW.6.2KW,11KW |
| Type | DC/AC Inverters | Output Type | Single Phase |
| Output Current | 50A, 30A, 10A | Output Frequency | 50/60 hz |
| Size | 420*350*110mm | Weight | 5.6kg |
| Efficiency | 0.98 | Inverter type | Hybrid Inverter |
| POWER | 3.2KW,4.2KW,6.2KW,11KW | Input Voltage | 230VAC |
| Battery Voltage | 24VDC 48VDC | Solar Charger Type | MPPT |
| Max. PV Array Power | 2000W,5000W,6200W,11000W | Max. Solar Charge Current | 80A,120A,160A |
| MPPT voltage range | 30-400VDC | Communication Interface | RS232/WIFI/GPRS |
