Description
Kinmore
The delivery cycle is 15 days
| Warranty | 3months-1year | Place of Origin | Guangdong, China |
| Brand Name | Kinmore | Model Number | RS-540SH-7520 |
| Use | BOAT, Car, FAN, Home Appliance, Vacuum Cleaner and RC Model | Type | Micro Motor |
| Torque | 325 g.cm | Construction | Permanent Magnet |
| Commutation | Brush | Protect Feature | vented |
| Speed(RPM) | 23400 ¡À10% rpm no load | Continuous Current(A) | 2.4A |
| Efficiency | IE 1 | Frame | 35.8*50mm |
| Rated voltage | dc 7.2v | Rated Power | 65.02W |
| Motor Mounting Type | Panel Mount | Speed Rpm | 23400 ¡À10% rpm no load |
| Rotor | 3 slots armature | Insulation of armature | Class F magnet wire |
| Stator | 2 poles permanent magnet | Motor Housing | Dia 35.8*L50mm |
| Type of brushes | Carbon | Rotation | CCW/CW reversible |
| Shaft | Dia3.175mm carbon steel | Certificate | ISO TS16949 |
| Weight: | ~157g | Certification | RoHS |
