Description
Kinmore
The delivery cycle is 15 days
| Warranty | 3months-1year | Place of Origin | Guangdong, China |
| Brand Name | Kinmore | Model Number | RS-540SH-6036-RoSH |
| Use | Car, Electric Bicycle, FAN, Home Appliance, RC Car/Vacuum Cleaner/RC Model | Type | Micro Motor, Permanent magnet Motor |
| Torque | 293.9 g.cm At Max Efficiency | Construction | Permanent Magnet |
| Commutation | Brush | Protect Feature | vented |
| Speed(RPM) | 19500rpm no-load | Continuous Current(A) | 5.51A(max8.3A)At Max Efficiency |
| Efficiency | IE 1 | Frame | 35.8*50mm |
| Rated voltage | DC 12V | Rated Power | 50.2W |
| Motor Mounting Type | Panel Mount | Speed Rpm | 19500rpm no-load |
| Rotor | 3 slots armature | Insulation of armature | Class F magnet wire |
| Stator | 2 poles permanent magnet | MOQ | Negotiable |
| Rotation | CCW/CW reversible | Shaft | Dia 3.175mm carbon steel Shaft |
| Standards | RoHs | Motor Housing | Dia35.8*50MM |
| Certification | RoHS |
