KINMORE
The delivery cycle is 15 days
| Warranty | 3months-1year | Place of Origin | Guangdong, China |
| Brand Name | KINMORE | Model Number | RS-987SHF-8009 |
| Use | BOAT, Outboard Marine, Recreational Vehicles, Yacht | Type | Micro Motor |
| Torque | 6200g.cm stall torque | Construction | Permanent Magnet |
| Commutation | Brush | Protect Feature | Vented |
| Speed(RPM) | 15000rpm No load | Continuous Current(A) | 2.6A No load |
| Efficiency | IE 1 | Frame | 51.8*69mm |
| Rated voltage | DC 12V | Rated Power | 112.1W at max efficiency |
| Motor Mounting Type | Panel Mount | Speed Rpm | 15000rpm No load |
| Certification | ISO/TS16949 | Material | SECD housing and SECC endcap |
| Shaft material | carbon steel | Brush shape | Carbon brushes |
| Stator | 2-poles stator | Rotor | 7 slots Armature |
| Rotation | Reversible | Bush on the driving side | cylinder sintered bronze bush |
| Bush on the endcap side | self-aligning sintered bronze bush | Insulation Class of Magnet Wire | Calss F |
