Kinmore
The delivery cycle is 15 days
| Warranty | 3months-1year | Place of Origin | Guangdong, China |
| Brand Name | Kinmore | Model Number | RS-550SH-25232R |
| Use | Car, Home Appliance, EPB/Air pump/Door Closer/RC model | Type | Dc Motor |
| Torque | 2200.00 g.cm at stall | Construction | Permanent Magnet |
| Commutation | Brush | Protect Feature | Totally Enclosed |
| Speed(RPM) | 4500¡À12% rpm | Continuous Current(A) | 0.54A |
| Efficiency | IE 1 | Frame | 35.8*57mm |
| Rated voltage | DC 24V | Rated Power | 10.24W |
| Motor Mounting Type | Panel Mount | Speed Rpm | 4500¡À12% rpm |
| Main Feature | High speed 4500rpm DC motor | Brush Type | Carbon Brush/Metal Brush |
| End cap | Plastic | Weight | 210g |
| Magnet | NdFeB magnet | Shaft end play | 0.05~0.55mm MAX |
| Shaft diameter | 3.175mm | Outline Diameter | 35.8mm |
| Typical Usage | Air conditioning,Vacuum Cleaner,EPB Valve,Air Pump,Power Tool |
