Kinmore Motor
The delivery cycle is 15 days
| Warranty | 3months-1year | Place of Origin | Guangdong, China |
| Brand Name | Kinmore Motor | Model Number | RS-390PH-4532R |
| Use | Car, Home Appliance, Headrest Adjuster,Drill,Vaccum Cleaner,Hair Dryer | Type | Micro Motor |
| Torque | Stall 1100 g.cm | Construction | Permanent Magnet, Permanent Magnet |
| Commutation | Brush | Protect Feature | Drip-proof |
| Speed(RPM) | 12800 ±10% rpm no load | Continuous Current(A) | 0.6 A |
| Efficiency | IE 1 | Frame | 27.7*46.5mm |
| Rated voltage | DC 6V | Rated Power | Output 18 W |
| Motor Mounting Type | Panel Mount | Speed Rpm | 12800 ±10% rpm no load |
| Motor housing Size | L 46.5mm * Dia 27.7mm | Noise | <50dB |
| Nominal voltage | 6.0 V DC | Operating Temperture | -10~ +60 |
| Way of commutation | brushes | Rotation | CW/CCW |
| End Play | 0.05~0.35 mm | Bearing kind | Sintered bronze bearing |
| Motor type | 6v dc electric motors |
