Penerangan
Kinmore
The delivery cycle is 15 days
| Warranty | 3months-1year | Place of Origin | Guangdong, China |
| Brand Name | Kinmore | Model Number | FF-180PHV-09400D |
| Use | FAN, Home Appliance, SMART HOME, RC Model/Toy/Electric Shaver/Tooth Brush/Mini Printer | Type | Micro Motor |
| Torque | 80g.cm At Stall | Construction | Permanent Magnet, Permanent Magnet |
| Commutation | Brush | Protect Feature | Closed |
| Speed(RPM) | 4500±10% rpm no load | Continuous Current(A) | 18mA(35mA Max) |
| Efficiency | IE 1 | Frame | 20.4*32.1mm |
| Rated voltage | DC 12V | Rated Power | / |
| Motor Mounting Type | Panel Mount | Speed Rpm | 4500±10% rpm no load |
| Structure | 2-poles magnet stator and 3-slots armature | Rated Voltage | 12V DC |
| Direction of Rotation | CCW or CW,Bi-direction | Shaft Type | Stainless steel shaft |
| Bearing Type | Oil-impregnated Bearing | Usage | Tooth Brush/RC Model/Toy/Electric Shaver/Mini Printer/Home Appliances |
| Option | Counterweight for option | End Cap | Metal End Cap |
| No Load Current | 18mA(35mA Max) |
