Penerangan
KINMORE
The delivery cycle is 15 days
| Warranty | 3months-1year | Place of Origin | Guangdong, China |
| Brand Name | KINMORE | Model Number | RS-997SH-5527 |
| Use | Car, Electric Bicycle, FAN, Home Appliance, Outboard Marine, Recreational Vehicles, Yacht | Type | Brush Motor |
| Torque | 1010mNm Stall torque | Construction | Permanent Magnet |
| Commutation | Brush | Protect Feature | Vented |
| Speed(RPM) | 6500rpm No load | Continuous Current(A) | 0.7A No load |
| Efficiency | IE 1 | Frame | 51.8*85mm |
| Rated voltage | DC 24V | Rated Power | 171.9w |
| Motor Mounting Type | Panel Mount | Speed Rpm | 6500rpm No load |
| Material | SECD housing and SECC endcap | Shaft material | carbon steel |
| Brush shape | Carbon brushes | Stator | 2-poles stator |
| Rotor | 7 slots Armature | Rotation | Reversible |
| Bush on the driving side | cylinder sintered bronze bush | Bush on the endcap side | self-aligning sintered bronze bush |
| Insulation Class of Magnet Wire | Calss F | Certification | rohs |
