Penerangan
Kinmore
The delivery cycle is 15 days
| Warranty | 3months-1year | Place of Origin | Guangdong, China |
| Brand Name | Kinmore | Model Number | FA-130SA-2180 |
| Use | FAN, Home Appliance, Toys | Type | Micro Motor |
| Torque | 13.3 g.cm | Construction | Permanent Magnet |
| Commutation | Brush | Protect Feature | Closed |
| Speed(RPM) | 12500 ¡À10% rpm no load | Continuous Current(A) | 0.23 A |
| Efficiency | IE 1 | Frame | 15.2*25mm |
| Rated voltage | DC 3V | Rated Power | / |
| Motor Mounting Type | Panel Mount | Speed Rpm | 12500 ¡À10% rpm no load |
| Motor housing | Dia20.1*F15.2*L25.0mm | Rotation | Reversible, bidirection |
| Structure | 2-poles magnet stator and 3-slots armature | Brush Type | Metal brushes |
| Shaft | Dia 2mm carbon steel Shaft | Endcap material | SECC |
| Option | vibrator, carbon brushes | Load | 10259rpm at 7.7g.cm |
| Operating Temperature | 0~45 degrees | Certification | RoHS |
